High-Speed PCB Design
High-speed, multi-layer, and rigid-flex PCB design optimized for DFM and signal integrity.
We specialize in ultra-dense, multi-layer high-speed PCB layouts engineered for optimum signal and power integrity. Our engineering workflow enforces strict DFM/DFA compliance, controlled impedance differential pair routing, microvia HDI stackups, and advanced thermal dissipation for demanding applications.
Key Technical Solutions
- Controlled impedance and high-speed signal routing (DDR4/5, PCIe, USB 3.2, Ethernet)
- High-density interconnects (HDI) with microvias and blind/buried via stackups
- Power Integrity (PI) & Signal Integrity (SI) simulation and plane optimization
- Rigid-flex and flexible circuit design for space-constrained packaging
- Comprehensive DFM (Design for Manufacturing) & DFA (Design for Assembly) rule checks
Tools & Equipment: KiCad Pro, Allegro PCB Editor, HyperLynx, Industry EDA
